Parameterization
In Profibus-systems bus errors can cause damage to personal or material
property. Please bear in mind, that activating the menu while operating
Profibus units may cause a bus error.
To start the menu, press both menu buttons simultaneously (approx. 1 sec.) until the
first menu item appears on the monitor display. Now, you can navigate in the menu
as follows:
Next menu item:
Page menu items forward:
Previous menu item:
Page menu items backward:
Next setting:
Page settings forward:
Previous setting:
Page setting backward:
Shortly press menu button [ ] in menu item U to quit the menu. Depending on the
setting in menu item U, the settings you made will be either saved (set), not saved
(escape) or the default settings will be restored with the exception of menu item 1
(default).
Canceling the menu without saving the settings made is possible by pressing both
menu buttons simultaneously (approx. 1 sec.) or will happen automatically if 60
seconds pass without a menu button being pressed.
Once the menu is closed, the unit behaves in the same manner as after power-on.
In the menu mode the character w appears in the main display. A control of the unit is
not possible.
The menu is shown in the following menu table. Default settings are marked with *.
Individual menu items or settings may be suppressed in another menu item
depending on the type of unit or setting.
30
Shortly press menu button [ ]
Press menu button [ ] long
Double click on menu button [ ]
Double click on button [ ] and keep it pressed
Shortly press menu button [ ]
Press menu button [ ] long
Double click on menu button [ ]
Double click on button [ ] and keep it pressed
BAL S202 PFB M 1.0
