These operating instructions are valid for units with the following type code:
S202-xx/06/0x-001/0B-K0
The 'x's in the model designation indicate the size and design of the units (see
'Technical data').
Dimensions
The following figure shows unit version SX202-06/05/0x-001/0B-K0 representing the
other unit versions listed in the following table.
Dimensions in mm
Panel cutout: (A – 7) x 89 mm
Units without dimension symbol
S202-02/06/0x-001/0B-K0
S202-03/06/0x-001/0B-K0
S202-04/06/0x-001/0B-K0
S202-05/06/0x-001/0B-K0
S202-06/06/0x-001/0B-K0
BAL S202 PFB M 1.0
A
A - 8
A
144 mm
192 mm
240 mm
288 mm
336 mm
2...6
Rear view
Profibus
interface
Rear view cutout
Units with dimension symbol
S202-F2/06/0x-001/0B-K0
S202-F3/06/0x-001/0B-K0
S202-F4/06/0x-001/0B-K0
S202-F5/06/0x-001/0B-K0
S202-F6/06/0x-001/0B-K0
61
3
Monitor display
Address
Lo
Hi
0
1
9
4
6
5
Menu buttons
9 1
0
0
1
9
4
4
6
5
6 5
0
1
9
4
6
5
A
192 mm
240 mm
288 mm
336 mm
384 mm
23
