Anleitung FW 500_SPK1 10.05.2006
GB
appliance, and slide the wall bracket (2) off the
back of the heater.
Mark the positions of the drill holes on the wall, drill
the holes and insert the dowels.
Screw the wall bracket horizontally to the wall,
Slide the back of the heater into the wall bracket
which is now fastened to the wall and secure it with
the screws on the side.
3.2 Using as a floor-mounted appliance
Slide the feet onto the rails (Fig. 5).

4. Technical data:

Rated voltage: 230 V ~ 50 Hz
Output:
Thermostat control: Infinitely adjustable
Protection type:
Mains lead: 3 x 0.75 mm2 x 1800 mm
Appliance dimensions, approx.: 300 x 110 x 255 mm

5. Proper use

The appliance is designed only for private use, not
for commercial heating purposes. It is designed for
antifreeze protection and temperature stabilization of
small rooms and for indoor use. You are allowed to
operate the heater only when it is mounted in a
stationary position. The heater is not intended for
outdoor use.
6. Starting up
Important! Before using the appliance for the first
time, check that the voltage supply is the same as
the voltage details set out on the data plate. Read
safety instructions listed under section 1.
When the heater is used for the first time or after a
long period of rest it may emit an odor for a short
time. This is not a fault. To totally shut down the
antifreeze heater with thermostat you must pull the
power plug.
6.1 Thermostat control/Room thermostat
(Fig. 1 / Item 2):
Switch on the required heating output. Turn the
control to "MAX" until the required room temperature
has been reached. Then turn down the control until
8
9:05 Uhr Seite 8
you hear a clear click. The thermostat control will
switch the radiator on and off automatically to
maintain the room temperature at an almost constant
level. However, this presupposes that the radiator
has sufficient output to cover the heating
requirements for the room.
Note: Turn the controller all the way to the left =
antifreeze setting (approx. 5°C to 8°C) The device
automatically switches itself on or off.
6.2 Overheating guard
In case of excessive heating, the heating function
shuts down automatically. If this occurs, turn off the
appliance, disconnect the mains plug and wait a few
minutes for the appliance to cool. After eliminating
the cause (e.g. a covered air grille), the appliance
500 watts
can be switched on again. If the overheating guard
triggers repeatedly, please contact your customer
service center (in Germany ISC GmbH).
IP24

7. Maintenance and cleaning

Before carrying out any cleaning and maintenance
work the appliance must be turned off,
disconnected from the power supply and cooled
down.
Maintenance and repair work may only be carried
out by an electrical servicing contractor or your
customer service center.
Check the mains lead at regular intervals for signs
of defects or damage. A damaged mains lead may
only be replaced by an electrician or the customer
service responsible for your country in compliance
with the relevant regulations.
Use a damp cloth to clean the casing.
Remove dust pollution with a vacuum cleaner.

8. Ordering spare parts

Please provide the following information on all orders
for spare parts:
Model/type of machine
Article number of the machine
ID number of the machine
Number of the required spare part
For our latest prices and information please go to:
www.isc-gmbh.info
