Setting sauna time
Sauna time is set when the heater is OFF. Use the function selection buttons (F) to select operating time
setting. Use the - and + buttons to then select operating time 1-10. Operating time depends on the max.
operating time set, i.e. which program has been set.
Version
1
1 h
6 min
6 h
1 h
10 h
1 h
24 h
2 h
Connecting door contact and its function
A magnetic contact to detect when the door is open can be connected. The contact to be used is Tylö
item number 90908035. The contact is connected to the heater according to the instructions supplied.
A door contact must be connected for the delayed start function. A door contact must also be connected
to use an external switch. If the heater has been programmed for delayed start and the door is opened
after the program is activated, the program will be disrupted and the indicator will fl ash. To reactivate the
program for delayed start, press the Start button and close the door within 60 seconds.
If the panel is placed inside the sauna, you have 60 seconds to go out and close the door once delayed
start has been activated.
If the door is opened and left open for more than 5 minutes during operation, the heater will be switched
off and error code 19 will show on the panel.
Using an external switch
An external switch for starting/stopping the heater not mounted on the control panel can be connected.
A door contact must be installed. See wiring diagram supplied with external switch for connection. We
recommend using Tylö's external switch (item number 90908045). This also provides indication via LED
of whether the sauna is on, programmed for delayed start and error status for a magnetic door contact
(if fi tted)
A continuous light indicates that the heater is on.
Slow fl ash indicates that the heater is programmed for delayed start.
Rapid fl ash indicates that the door has been opened when the heater is programmed for delayed start.
Alternatively, the door has been open for more than 5 minutes during operation or has been opened
after the heater has been switched off. The control panel will then require resetting.
2
3
4
12 min 18 min 24 min 30 min 36 min 42 min 48 min 54 min
2 h
3 h
4 h
2 h
3 h
4 h
4 h
6 h
8 h
LED indicators
5
6
7
5 h
6 h
5 h
6 h
7 h
10 h
12 h
14 h
11
8
9
10
1 h
8 h
9 h
10 h
16 h
18 h
24 h
