Connecting a flash to the Strato Multi
transmitter or receiver hot shoe
1. Turn off the flash and the Phottix Strato Multi
Transmitter or Receiver.
2. Slide the flash into the transmitter's or receiver's hot
shoe mount.
3. Lock the flash with the flash's locking mechanism.
4. Turn on the flash and the Phottix Strato Multi receiver.
5. Set the flash to Manual mode (receiver only – no TTL
data is transmitted).
* It is not unusual for the flash to discharge once after
turning on the Phottix Strato Multi.
Connecting the Strato Multi receiver
by cable
1. Turn off the flash/strobe and the Phottix Strato Multi
receiver.
2. Connect a cable to the receiver's 3.5 mm PC Sync Port.
3. Connect the opposite end of the cable to a flash or
studio strobe (A 6.3 mm adapter is included for studio
strobes with larger ports).
4. Turn on the flash/strobe and the Phottix Strato Multi
receiver. Set the flash to Manual mode.
En
* It is not unusual for the flash to discharge once after
turning on the Phottix Strato Multi.
Using the Strato Multi as a wireless
shutter release*
1. Turn off the camera and the Phottix Strato Multi
receiver.
2. Attach the correct Phottix Accessory Cable for your
camera make and model to the 2.5 mm Accessory Port
on the Strato Multi receiver
3. Attach the other end of the cable to the camera's
remote port.
4. Turn on the camera and Phottix Strato Multi receiver.
Consult your camera manual for specific settings for
remote use.
5. Using the Phottix Strato Multi transmitter will allow
for remote wireless shutter release functions. The Strato
Multi shutter button functions the same as a camera
shutter button: A half-press of the test/shutter button
will autofocus, a full press will take a photo.
*On compatible cameras
