Lay the door in a safe location with the door's outer surface
d
facing upward.
NOTE:
damage to its cosmetic coating.
3 Repeat step a through step d for the left back door.
Replacing the Back Doors
To replace the back doors, follow the steps for removing the back doors in the
reverse order.

Removing and Replacing the Side Panels

NOTE:
Remove the lower side panels in order to install the side brushes and the
side stabilizer feet.
NOTE:
Although removing the side panels is not mandatory for installing
systems in a rack, having the sides open makes it easier to install slide assemblies
and support rails and to reverse the direction that the front door opens.
Removing the Upper Side Panels
1 Push both latches up and swing the bottom end of the panel away
from the rack. See Figure 4.
2 Grasp firmly on each side of the panel.
3 Lift the panel upward until the panel lip clears the top of the rack.
4 Lay the panel in a safe location with the panel's outer surface facing
upward to prevent damage to its cosmetic coating.
5 Repeat step 1 through step 4 for the other upper side panel.
Replacing the Upper Side Panels
1 Lift the upper side panel up onto the rack, hooking the panel lip over the
top of the rack. See Figure 4.
2 Swing the bottom of the panel downward onto the rack.
3 Press the panel into the rack until both latches lock into place.
Lay the door flat with the outer surface facing upward to prevent
Installation Guide
13
