Specifications

Input Voltage...................230-240 VAC, 50 Hz
Max. Pull Force ..............700 N (COMFORT), 1000 N (PREMIUM)
Standby Power
(door fully closed)...........0.8 W
Motor
Type................................DC gearmotor permanent lubrication
Noise level......................54dB
Drive Mechanism............Belt
Length of Travel..............Adjustable
Opening speed, up to ....160 mm/s (COMFORT), 200 mm/s (PREMIUM)
Lamp...............................On when door starts, off 2-1/2 minutes
after stop.
Door Linkage ..................Adjustable door arm. Pull cord trolley release.
Safety
Personal .........................Push button and automatic stop in down
direction. Push button and automatic stop in
up direction.
Electronic........................Automatic force adjustment
Electrical .........................Transformer overload protector and low
voltage push button wiring.
Limit Device ....................Mechanical RPM/Passpoint detector.
Limit Adjustment .............Electronic
Soft-Start / Soft-Stop........all
Dimensions
Length (Overall)...............3200 mm
Headroom Required .......30 mm
Hanging Weight ..............~12 kg
Receiver
Memory Registers ..........180
Operating Frequency.......6-Band (433 MHz / 868 MHz)
SPECIAL NOTE: Chamberlain strongly recommends installing photocells
on all garage door openers.
36

Service parts / Warranty

Please refer to www.chamberlain.eu or contact your local dealer.
Also refer to the available Warranty Book.
37

Declaration of conformity

The manual consists of these operating instructions and the declaration of
conformity.
