_ USING THE SUN VISOR
The CONCORD WANDERER's sun visor
(01) can be locked into place in 4 positions.
The rear portion of the sun visor can be
opened using the zip fastener to ensure
better ventilation.
36
manual_WANDERER_130109-WEST-final.indd 36
To attach the CONCORD WANDERER's sun visor
(01) to the seat unit (04), carefully insert the sun
visor's adapters into the matching sockets on the
seat unit and push until they lock into place.
Now use the Velcro fastener to attach the sun visor
to the seat cover.
To remove the sun visor (01), first undo the Velcro
fastener between the sun visor and the seat cover.
Press the release levers on the sun visor adapters
and pull the sun visor upwards to remove it.
