Field Of Application - grabner XR TREKKING Eignerhandbuch

INDEX
Pruduct illustration
Part description
List of items
Specification

Field of application

Assembly
Dismantling
Handling + details
Accessories
Declaration of conformity
lIST Of ITEMS
1 Hull
2 Seat-boards
2 Carrying belts
1 Repair kit incl. valve key and bayonet
adapter
SpECIfICaTION
Length:
Beam:
Net weight:
No of persons:
Carrying capacity:
Operating pressure:
Motor output:*
Motor weight:*
WW-Class:
Norm:
Category:
* = with outrigger only!
fIElD Of applICaTION
► Canoe for 2 persons, on lakes, rivers
and sheltered coastal close waters.
Page
11
XR TREKKING
400 cm
95 cm
20 kg
2 adults
280 kg
0,3 bar
2,2 kw - 3 HP
17 kg
4
ISO-EN 6185/III
D
► White-water suited boat to level of diffi-
culty grade 4, - passage complexity so-
mewhat uncertain and usually requires
2
scouting, continuous swell, powerful
swirl, surge and torrent wash.
2
WaRNING: White-water exploration to
7
Grade 3, with spray-cover, or bailing re-
7
quired, possible for experienced paddlers
7
only.
7
► Motorisation to max 2.2KW/ 3HP -
With outrigger only!
8
8
9
► Open and empty the carton, of your boat
and the footrests.
► Check the list of items to ensure no parts
are missing.
► Remove the wrapping foil and unroll the
boat.
► Inflate bottom and side tubes till they
reach approximate final shape.
► Remove the knurled nuts of the seat-
boards and insert them from underneath
into the seat-board eyelets, fasten the
nuts.
► Fasten the forward part of the seat-
boards to the eyelets of the coaming by
means of the straps.
► The tilt of the seat-boards can be ad-
justed to suit by tensioning or loosening
the straps.
► Now only inflate your boat to full opera-
ting pressure (0.3 bar).
aSSEMBly
7
