grabner TRAMPER Handbuch Seite 11

ASSEMBly
►
Open and empty the carton of your boat.
►
Check the list of items to ensure no parts
are missing.
►
Unroll the boat.
►
Close the valves by pushing and twist the
green button clock- or anti clockwise by a
quarter turn. If valve is closed, the green
button stands out.
►
Inflate side tubes and bottom till they
reach approximate final shape.
►
Insert the bayonet nozzle adapter of tube
of the inflation appliance (bellow pump,
electric- or other air pump), into the so-
cket of the airvalve and twist the bayonet
nozzle clockwise.
►
Now inflate the boat as far, so that the
final shape becomes apparent.
See „Valve - Inflation" in the Operating Inst-
ructions - Part 2.
►
Insert the footrest into the desired posi-
tion between the bottom and the side tu-
bes (short bar forward long footrest rear).
- not standard for TRAMPER.
►
For use the steering device or Torqeedo
sternmotor insert the stainless stern bra-
cket in the link at rear.
►
First insert the stern bracket from bottom
in the upper link and then back from top
into the lower link.
►
Now only inflate your boat to full opera-
ting pressure (0.3 bar).
►
Cover the valve with the valve cap (ba-
yonet cap).
SEATS
TRAMPER, HOLIDAY
►
Fix the seats with the hooks on the D-
rings.
►
Adjust the seating position with the side
straps.
11
