1.1. Cleaning the cabinet
Clean only with a damp, soft cloth and a commercially available mild
household cleanser. Ensure, that no water gets inside the equipment
to prevent possible shorts and damage to the equipment.
1.2. Safety symbols
Double insulation, protection class II
Attention! Refer to the manual
1.3. Input limits
Function Input limits
ACA P 1630: 200A/P 1635: 80A
P 1630:±200A/P 1635: ±80A
DCA
Frequency (only P 1630) 1 kHz
2. Introduction
2.1. Unpacking and inspection
Unpon removing your new Clamp Meter from it´s packing, you should
have the following items:
1. Clamp meter
2. Carrying case
3. Instruction manual
-16-
1. Zange, zur Messung von Gleich – und Wechselströmen in Leitern
2. Taste zum Einschalten der Taschenlampe
3. Funktionswahlschalter
4. DATA-Hold Taste, Hintergrundbeleuchtung
5. LCD-Anzeige
6. Zangenöffner
7. DCA-Zero-Taste
4.1. Display
(1) AC DC
(2) -
(3) HOLD
(4) BAT
(5) Hz
AC: Wechselstrom
DC: Gleichstrom
Minus-Zeichen
DATA-Hold
Batteriezustandsanzeige
Frequenzanzeige für ACA-
Messung (nur P 1630)
-9-
