Configuration
Once the system is correctly assembled and connected to a power source,
you may need to configure the controller's software.
Switch the On/Off switch to On.
After about 5 seconds the Pearpoint splash screen will be displayed for
about 5 seconds.
This will be followed by the welcome screen:
• Check that the date and time are correct and that the correct video
standard for your country (PAL or NTSC) is displayed.
• Check that the correct reel size is set.
• If a USB Flash Drive or CF card is present, check that the correct memory
parameters are displayed (if both a USB drive and CF card are present
then only the USB drive parameters will be displayed).
Press OK or Enter to continue.
If required you can set up the correct reel type, date, time and language
as follows:
To navigate through the system software use the keypad or keyboard
function and arrows keys. Use the
Use the and
to accept the selection.
Select the correct reel
Select "Menu" (F1 key) to go to the main menu screen, select "Set-up" and
press OK.
Select "Reel", press OK to continue to the Reel Setup Menu.
Use the or keys to select the correct reel length and type, press OK
to confirm your choice.
Press to exit the Reel Setup Menu.
Basic Controller Set-up
From the main Setup Menu, select "Controller" and press OK .
Select "Basic Settings" and press OK.
Select the setting you wish to edit and press OK or Enter.
Use the keyboard to modify Time or Date and use the
scroll through the various options.
Press OK to accept the new settings.
When all the required settings have been setup, press F6 to exit to the
top-level screen.
tFt Screen Settings
The screen brightness and contrast functions are available on the top
level screen.
Press BRI (F5) to set the Screen Brightness or CONTR (F6) to set the
Screen Contrast.
Use the and
your settings.
keys to scroll through the various options and press OK
keys to set the desired value and press OK to accept
key to return to the previous menu.
8
and keys to
