Quick start procedure
• Install the controller on top of the camera reel if desired (optional on
the P341 models).
• Connect the link cable to the connectors on the rear of the controller
and on the pushrod reel.
• Ensure a compatible removable storage device, FAT32 formatted, is
loaded into the controller (Compact Flash or USB Flash Drive).
• Connect the power supply to the controller.
• Switch the controller on.
• Press OK to clear the splash screen.
• Calibrate and zero the camera's position. Press F10 on the keyboard
or and on the keypad simultaneously.
• Deploy the camera into the pipe as required.
• If required zero the camera's position by pressing F10 on the keyboard or
press and
• On the keypad, press the
Enter job details if required:
• Review Client Name, Site Address and Survey Start and Finish Survey
references by pressing the
OK, again, to accept the changes.
• On the keypad, press the
inspection.
• Press the
Site Address and Survey Start and Finish references as described for
video recording).
• Press the key then press F1 to annotate your video.
• Press OK or enter to make an observation.
• To pause a recording, press
• To stop a recording, press
NOte: Do not extract the removable storage device during recording or
playback. Doing so may corrupt all data on the storage device and crash
the controller.
on the keypad simultaneously.
key to record the inspection.
key to take screen captures (if required review Client Name,
.
and keys. Press OK to Edit and press
key again to start recording the
.
