Setup
Cable reel
Connect the link cable to the cable reel socket and to the controller socket
and ensure that the connectors have been tightened.
Power lead
WARNiNG! the controller is not earthed. if any mains operated
equipment is connected to the system, the external equipment
MUSt Be earthed in accordance with the manufacturer's instructions.
Failure to earth the attached equipment may result in potentially
lethal electric shock.
Release the side catches and open the two halves of the cover.
Open the connection panel cover:
1 If required, connect the keyboard to the keyboard socket.
2 Connect the power supply (12 to 24V DC vehicle supply, mains
adaptor or optional battery pack) to the power socket.
3 Insert a suitable Compact Flash Card or USB Flash Drive formatted
as FAT32.
Recommended Camera Focus Settings
You should focus your camera to match the internal diameter of the pipe
you are about to inspect.
With reference to Tables 1 and 2 place your camera at the required distance
from a target object to get optimal image quality.
Use the focus tool provided with your camera to turn the focusing ring
until the target object is in focus.
table 1
internal Pipe Diameter
inches
1.25
1.5
2
3
4
table 2
internal Pipe Diameter
inches
2
3
4
6
8
9
1" (25mm) Camera
mm
32
38
51
76
102
2" (50mm) Camera
mm
51
76
102
152
203
229
target Object
inches
3.0
3.6
4.8
7.2
9.6
target Object
inches
5.6
8.4
11.2
16.8
22.4
25.2
7
mm
76
92
122
183
244
mm
142
213
284
427
569
640
