Screen Display - Bresser Translucidus Schnellstartanleitung

5 | Imprint
13 Battery compartment (Remote sensor)
15 °C/°F button (temperature format setting)
17 Stand, fold-out
Scope of delivery
Base station (A), remote sensor (B)
Recommended batteries (not included)
4 pcs. Micro batteries (1.5V, AAA type)

5 Screen display

1
19
18
17
16
Illustration 2: Screen display for base station (left) and remote sensor (right)
1 AM/PM information in 12-hour time mode
3 Symbol for active alarm
5 Symbol for active daylight saving time (DST)
7 Graphical weather trend display
9 Battery level indicator (Base station)
11 Indoor humidity value
13 Indoor temperature value
15 Outdoor temperature value
17 Selected channel for remote sensor
19 Symbol when snooze function is activated
21 Symbol for radio signal
23 Selected transmission channel
12 / 15
4
2 3
15 14 13
14 CH button (Channel setting)
16 Wall mount
5 6 7 8
12 11
2 Standard: Current time; Alarm: Alarm time
4 Symbol for active time zone
6 Current date
8 Symbol for radio signal
10 Indoor humidity information
12 Indoor temperature information
14 Battery level indicator (Remote sensor)
16 Symbol for temperature alarm (highest or low-
est value)
18 Outdoor temperature information
20 Battery level indicator (Remote sensor)
22 Outdoor temperature value
QS_7007600000000_de_en_BRESSER_v1116
20 21 22
9
7
23
10
