4. Handling of functions and programs

Function
Zero point adjustment
Start SETUP
OFFSET
Adjustment
Adjust + / -
Select next digit
Adjustment
upwards
Adjustment
downwards
Quitting
Adjustment of the tolerance limits in ABS
Start SETUP
TOL
Adjust lower toler-
ance limit
Adjust first digit
Select second digit
Adjust second digit
Select third digit
Adjust third digit
Select fourth digit
Adjust fourth digit
Switch over to
TOL UP
Basic Action
2x
Result
SETUP Menu can be started within every
measuring mode
Possible 0 point adjustment according to
resolution in certain ranges (see "9. Technical
Details"). If the absolute OFFSET is exceed-
ed, the error report ERR 07 is shown.
unsigned
= plus
signed
= minus
Applies for the blinking digit (scale interval
0,005mm = 3 decimal places)
SETUP Menu can be started within every
measuring mode
Example: 10,00 +/- 0,05mm
SETUP Menu can be started within every
measuring mode
Lower tolerance limit
Attention!
TOL LO must be lower than TOL UP
After short TOL LO display the last saved
value will be shown
MODE counts upwards
DATA counts downwards
Number of digits depending on the scale
interval
After short TOL UP display the last saved
value will be shown
20
Remarks
