26 X-TOUCH EXTENDER
X-TOUCH EXTENDER MIDI Send
Encoder Bu on Press: Note On (Value 127), Bu on release: Note O (Value 0
CC 80 CC 81 CC 82 CC 83
Note 0 Note 1 Note 2 Note 3
(C-1) (C#-1) (D-1) (D#-1)
Encoder Press
Note 8 (G#-1) Note 9 (A-1) Note 10 (A#-1) Note 11 (B-1)
Note 16 (E0) Note 17 (F0) Note 18 (F#0) Note 19 (G0)
Note 24 (C1) Note 25 (C#1) Note 26 (D1) Note 27 (D#1)
Note 32 (G#1) Note 33 (A1) Note 34 (A#1) Note 35 (B1)
Bu on Press: Note On (Value 127), Bu on release: Note O (Value 0)
Fader Touch
Note 110 (D8) Note 111 (D#8) Note 112 (E8) Note 113 (F8)
CC 70 CC 71 CC 72 CC 73
Fader Move
Fader Touch: Note On (Value 127), Fader release: Note O (Value 0)
Fader Move: Fader Values (min to max posi on): 0...127
* In CTRL Mode:Encoder Rotation Values (left to right end): 0...127
* In CTRL REL Mode:Encoder Rotation Left turn (decrement) = value 1 / Right turn
(increment) = value 65
Apart from the diff erence to the Encoder Rotation function, CTRL mode and CTRL REL
mode are identical
* En el modo CTRL: Valores de giro de mandos giratorios (izquierda a tope derecho): 0...127
* En el modo CTRL REL: Giro de mando giratorio Giro hacia la izquierda (disminución) = valor 1 / Giro
hacia la derecha (aumento) = valor 65
Aparte de la diferencia de la función de giro de los mandos giratorios, los modos CTRL y
CTRL REL son idénticos.
* En mode CTRL : Valeurs de la rotation des encodeurs (de gauche à droite) : 0...127
* En mode CTRL REL : Rotation de l'encodeur Rotation vers la gauche (décrémentation) =
valeur 1 / Rotation vers la droite (incrémentation) = valeur 65
À l'exception de la diff érence de valeur pour la rotation des encodeurs, les modes CTRL et CTRL REL
sont identiques.
CC 84 CC 85 CC 86 CC 87
Note 4 Note 5 Note 6 Note 7
(E-1) (F-1) (F#-1) (G-1)
Note 12 (C0) Note 13 (C#0) Note 14 (D0) Note 15 (D#0)
Note 20 (G#0) Note 21 (A0) Note 22 (A#0) Note 23 (B0)
Note 28 (E1) Note 29 (F1) Note 30 (F#1) Note 31 (G1)
Note 36 (C2) Note 37 (C#2) Note 38 (D2) Note 39 (D#2)
Note 114 (F#8) Note 115 (G8) Note 116 (G#8) Note 117 (A8)
CC 74 CC 75 CC 76 CC 77
* Im CTRL-Modus: Werte bei Reglerdrehung (links nach rechts bis Ende): 0...127
* Im CTRL REL-Modus: Reglerdrehung Linksdrehung (Verringerung) =
Wert 1 / Rechtsdrehung (Erhöhung) = Wert 65
Abgesehen von der unterschiedlichen Reglerdrehungs-Funktion sind der CTRL- und der
CTRL REL-Modus identisch.
* Em CTRL: Valores Rotatórios do Codifi cador (esquerda para direita): 0...127
* Em Modo CTRL REL: Rotação do Codifi cador Virando à esquerda (diminuição) = valor 1 / Virando à
direita (aumento) = valor 65
Além da diferença da função Encoder Rotation, o modo CTRL e o modo CTRL REL são idênticos.
Using the X-TOUCH
EXTENDER
The X-TOUCH EXTENDER can be used as an RTP MIDI
Using X-TOUCH EXTENDER as an RTP MIDI
device over a Network connection. This is useful in
device within OS X
systems where long USB cables would otherwise
be required. For OS X systems, no external driver is required for
RTP MIDI operation.
The following instructions show the general
preparation of the X-TOUCH EXTENDER for RTP MIDI Slave
operation, and then further details for use with an
1. Make sure your computer and the
OS X* network, and a Windows* network.
X-TOUCH EXTENDER are within the
Preparing the X-TOUCH EXTENDER for RTP same network.
MIDI operation
2. Open AUDIO/MIDI-Settings on the computer.
1. On the X-TOUCH EXTENDER, press and hold the 3. Open MIDI Studio / MIDI Devices window.
SELECT button of CH1 during power up, to enter
4. Double-click on "Network."
the Settings menu. Observe the text in the
5. Click on "+" underneath the DIRECTORY fi eld
scribble-strip displays.
to add a device. Insert Name, the IP of your
2. Turn the 2nd encoder to select NETWORK.
X-TOUCH EXTENDER and the port (5004).
3. The 3rd encoder allows you to select either
6. Create a Session by pressing "+" underneath
MODE or DHCP:
the "My Sessions" fi eld and activate the
• MODE selects between using the session created.
X-TOUCH EXTENDER as an RTP SLAVE or an RTP
7. Activate the X-TOUCH EXTENDER and
MASTER. In SLAVE mode, you need to enter the
click "Connect."
IP address of the X-TOUCH EXTENDER into your
8. The X-TOUCH EXTENDER is now available
computer's RTP MIDI settings. In MASTER mode
as an RTP MIDI controller. Open the
you can enter the IP address of the computer by
preferences of your DAW and add it as
turning the 3rd encoder one tick to the right,
control surface. Within most DAWs, it will be
and use encoders 4-7 to enter the sets of 3-digits
detected automatically.
that make up the address. You may use Port 5004
Master
in both cases, as this is the standard port for
RTP MIDI.
1. Make sure your computer and the X-TOUCH
EXTENDER are within the same network.
• DHCP can be set to ON or OFF. When DHCP is set to
ON, the X-TOUCH EXTENDER will get its IP address 2. Open AUDIO/MIDI-Settings on the computer.
automatically within the connected network
3. Open MIDI Studio / MIDI Devices window.
from the DHCP server. When DHCP is set to OFF,
4. Double-click on "Network."
the IP, Subnet mask, and Gateway have to be
5. Create a Session by pressing "+" underneath
entered manually by turning the 3rd encoder to
the "My Sessions" fi eld and activate the
the right and accessing the following pages: my
session created.
IP, my Mask, and my Gway. You can enter the IP
addresses using encoders 4-7. 6. For "Who may connect to me:" choose
"Anyone." X-TOUCH EXTENDER should appear as
4. Exit the X-TOUCH EXTENDER setup by pressing
a participant of the session.
the SELECT button of CH1 again. You will see the
7. The X-TOUCH EXTENDER is now available
following in the display: IP: 000.000.000.000
as an RTP MIDI controller. Open the
Wait...
preferences of your DAW and add it as
5. The IP will fi rst switch to an internal IP before
control surface. Within most DAWs, it will be
it shows the actual IP (for example IP:
detected automatically.
010.100.001.029) within the network when
DHCP is used. When the X-TOUCH EXTENDER is
connected to the computer via the network,
the Wait message will disappear.
*OS X is a trademark of Apple Inc.
*Windows is either a registered trademark or trademark of Microsoft Corporation in the United States and/or other countries.
Quick Start Guide 27
with RTP MIDI
Using X-TOUCH EXTENDER as an RTP MIDI
device with Windows
Windows systems require the use of a third-party
external driver for RTP MIDI. For example, do an
internet search for "rtpMIDI" then download and
install it on your computer.
Slave
1. Make sure your computer and the
X-TOUCH EXTENDER are within the
same network.
2. Open the rtpMIDI driver.
3. Click on "+" underneath the DIRECTORY fi eld
to add a device. Insert Name, the IP including
port address (e.g. 10.100.1.29:5004) of your
X-TOUCH EXTENDER.
4. Create a Session by pressing "+" underneath
the "My Sessions" fi eld and activate the
session created.
5. Activate the X-TOUCH EXTENDER and
click "Connect."
6. The X-TOUCH EXTENDER is now available as an
RTP MIDI controller. Open the preferences of
your DAW and add it as control surface.
Master
1. Make sure your computer and the
X-TOUCH EXTENDER are within the
same network.
2. Open the rtpMIDI driver.
3. Create a Session by pressing "+" underneath
the "My Sessions" fi eld and activate the
session created.
4. For "Who may connect to me:" choose
"Anyone." X-TOUCH EXTENDER should appear as
a participant of the session.
5. The X-TOUCH EXTENDER is now available as an
RTP MIDI controller. Open the preferences of
your DAW and add it as control surface.
