8

Assembly

• High-pressure cleaner*
• Adapter*
• Spray gun*
* = may not be included in the scope of delivery!
8.1 Fit the lance (2) and extension (1)
(Fig. 3)
1. Screw the lance (2) onto the thread of the patio
cleaner in a clockwise direction.
2. To attach the extension (1), press the release but-
ton (2a) and place the extension (1) onto the lance
(2). Then turn the extension (1) until it audibly clicks
into place.
3. To connect the lance (2) or extension (1) to the
high-pressure cleaner, place the extension (1) or
lance (2) onto the spray gun and turn it until it clicks
into place.
4. When using the extension (1), screw the union nut
(1a) against the spray gun.
8.2 Fitting the adapter
The following adapters can be used with the product
(see 13.1)
1. Press the adapter into the connection of the spray
gun of the high-pressure cleaner.
2. Turn the adapter until it clicks into place.
3. Proceed further as described under 8.1.
9

Operation

ATTENTION
Always make sure the product is fully assembled
before commissioning!
ATTENTION
Only operate the product in an upright position, never
in a lying position.
WARNING
If there are leaks in the water system, switch off the
product immediately and disconnect the product from
the mains immediately.
There is a danger of electric shock!
Start connecting the water connections again.
9.1 Regulating the pressure (Fig. 1, 4)
You can regulate the pressure of the water jet by turn-
ing the pressure regulator (3). The rotational speed of
the nozzles (5) changes accordingly.
12 | GB www.scheppach.com · service@scheppach.com
1. Turn the pressure regulator (3) clockwise to in-
crease the pressure (+) or anticlockwise to de-
crease the pressure (–).

10 Working instructions (Fig. 1)

WARNING
Pay attention to the recoil force caused by the emer-
gent water jet.
Ensure that you have secure footing and hold the
spray gun firmly.
Otherwise, you could injure yourself or others!
• Only activate the high-pressure jet of your high-
pressure cleaner once the patio cleaner is posi-
tioned on the surface to be cleaned.
• When cleaning wall surfaces, always hold the prod-
uct by the handle (4).
• Do not run the product over free-standing corners.
• The product is not suitable for scouring or scrub-
bing.

11 Cleaning and maintenance

WARNING
Have maintenance and repair tasks that are
not described in this operating manual, car-
ried out by a specialist workshop. Use only
original spare parts.
WARNING
Improper maintenance or cleaning work
can cause injuries!
WARNING
The product may start unexpectedly and cause
injuries and burns during cleaning, repair and
maintenance work.
– Switch the product off.
– Pull out the mains plug.
– Allow the product to cool.
11.1 Cleaning
WARNING
Do not spray the product with water or clean it under
running water. There is a danger of electric shock
and the product could be damaged.
