Model:
RG10F(B2)/BGEF
( Fresh feature is not available)
RG10F1(B2)/BGEF
RG10F1(B2)/BGCEF
(Cooling only model, HEAT
mode are not available)
Description
No.1
No.2
No.3
7
8
9
10
No.4
11
12
No.5
No.6
13
14
No.7
No.8
No.9
No.10
No.11
No.12
No.13
No.14
ON/OFF
Turns the unit on or off.
TEMP
Increases temperate in
°C increments.
Max. temperature is
30°C.
SET
Scrolls through operation functions as follows:
( ) AP mode( ) Fresh...
The selected symbol will flash on the display area,
press the OK button to confirm.
TEMP
Decreases temperature in 1°C increments.
Min. temperature is 16°C.
NOTE: Press together
for 3 seconds will alternate the temperature display
between the °C & °F.
FAN SPEED
Selects fan speeds in the following
order:AUTO LOW MED HIGH
TIMER ON
Sets timer to turn unit on (see How to Use Basic
Functions for instructions).
MODE
Scrolls through operation modes as follows:
AUTO COOL DRY HEAT FAN
NOTE: Please do not select HEAT mode if the machine
you purchased is cooling only type.Heat mode is not
supported by the cooling only appliance.
SHORTCUT
Used to restore the current settings
or resume previous settings.
OK
Used to confirm the selected functions.
SWING
Starts and stops the horizontal
louver movement. Hold down
for 2 seconds to initiate vertical
louver auto swing feature.
TIMER OFF
Sets timer to turn unit off (see How to Use Basic
Functions for instructions).
I SENSE
Press this button to activate the
I SENSE mode.
SLEEP
Saves energy during sleeping hours.
LED
Turns indoor unit's LED display and
air conditioner buzzer on and off
(model dependent), which create a
comfortable and quiet environment.
32
& buttons at the same time
Fresh
