Bosch AVIOTEC IP starlight 8000 Schnellstartanleitung Seite 5

AVIOTEC IP starlight
8000
6
d
max
[m]
d
max
[m]
Bosch Sicherheitssysteme GmbH
4.1
100°
w
0.3 m
12.6
0.5 m 21.0
0.7 m 29.5
1 m 42.1
1.25 m 52.7
1.5 m 63.2
4.1
100°
w
0.3 m
8.4
0.5 m 14.1
0.7 m 19.7
1 m 28.1
1.25 m 35.1
1.5 m 42.2
Graphics | All
d
max
w
w
90° 60° 45°
13.8 19.2 25.1
23.0 32.0 41.9
32.2 44.9 58.7
46.0 64.1 83.9
57.5 80.2 104.9
69.0 96.2 125.9
90° 60° 45°
9.2 12.8 16.7
15.3 21.4 27.9
21.5 29.9 39.0
30.7 42.8 55.7
38.4 53.5 69.6
46.0 64.2 83.6
2017.04 | 4.0 | F.01U.317.838
