Routing with Parallel Guide (see figure H)
For edge-parallel cuts, mount the parallel guide 17.
– Fasten the parallel guide 17 to the routing base 2 with the
knurled screw 16.
– Adjust the desired depth setting with wing bolt 18 on the
parallel guide.
– Guide the switched on power tool with uniform feed and
lateral pressure on the parallel guide alongside the work-
piece edge.
Routing with Roller Guide (see figure I)
The roller guide 19 is used for routing edges with router bits
without pilot or ball bearing.
– Fasten the roller guide to the routing base 2 with knurled
screw 16.
– Guide the machine with uniform feed alongside the work-
piece edge.
Lateral Clearance: In order to change the amount of material
removal, the lateral clearance between workpiece and the
guide roller 22 of the roller guide 19 can be adjusted.
– Loosen wing bolt 20, adjust the desired lateral clearance
by turning wing bolt 21 and tighten wing bolt 20 again.
Height: Adjust the vertical alignment of the roller guide de-
pending on the router bit in use and the thickness of the mate-
rial to be worked.
– Loosen knurled screw 16 on the roller guide, move the roll-
er guide to the desired position and tighten the knurled
screw again.
Mounting the Base Cover Sleeve (see figure J)
Intensive use of the power tool will cause the routing base to
become hot. In this case, a base cover sleeve (accessory) can
be mounted for protection of the hands.
– Remove the clamping lever 10.
– Place the base cover sleeve 23 on the routing base 2 from
above.
– Reassemble the clamping lever again in such a manner that
the motor unit 1 is held securely in the routing base when
the clamping lever is locked.
Routing with Tilt Base (see figures K–M)
The tilt base 24 is particularly suitable for flush routing of lam-
inated edges at hard to reach locations, for routing special an-
gles as well as for beveling edges.
When beveling edges using the tilt base, the router bit must be
equipped with a pilot or a ball bearing.
For mounting of the tilt base, follow the work steps in section
"Mounting the Routing Base" (page 16) accordingly.
To achieve precise angles, the tilt base 24 is equipped with
adjustment notches in steps of 7.5°. The complete adjust-
ment range is 75° (45° toward the front and 30° toward the
rear).
– Loosen both wing bolts 25.
– Adjust the requested value using the scale 26 and tighten
the wing bolts 25 again.
Bosch Power Tools
Changing the Guide Plate (see figure N)
The side-handle subbase 30 can be mounted in place of the
guide plate 6. It offers an additional handle 12 as well as a
connection possibility for dust extraction.
– Unscrew the four pan head screws on the bottom side of
the guide plate 6 and remove the guide plate.
– Screw the side-handle subbase 30 to the base plate with
the fastening screws provided.
In order to connect dust extraction, an extraction adapter 29
must be mounted to the side-handle subbase 30.
– Screw the extraction adapter to the guide plate with the
two screws provided.
– Connect an extraction hose (Ø 35 mm) to the mounted ex-
traction adapter.
– To ensure optimum dust extraction, the extraction adapter
should be cleaned regularly.
When working edges, additionally use the extraction hood 28.
– Mount the extraction hood between the side-handle sub-
base 30 and the extraction adapter 29.
– Remove the extraction hood again for working smooth face
surfaces.
The machine can be plugged directly into the receptacle of a
Bosch all-purpose vacuum cleaner with remote starting con-
trol. The vacuum cleaner starts automatically when the ma-
chine is switched on.
The vacuum cleaner must be suitable for the material being
worked.
When vacuuming dry dust that is especially detrimental to
health or carcinogenic, use a special vacuum cleaner.
Readjusting the Clamping Lever (see figure O)
When the motor unit 1 is no longer tightly seated in the routing
base, the tensioning force of the clamping lever 10 must be
readjusted.
– Open the clamping lever.
– Turn nut 31 approx. 45° in clockwise direction with an
open-end spanner (size 8 mm).
– Tighten the clamping lever again.
– Check if the motor unit is clamped securely. Do not over-
tighten the nut.

Maintenance and Service

Maintenance and Cleaning

Before any work on the machine itself, pull the mains
plug.
For safe and proper working, always keep the machine
and ventilation slots clean.
If the replacement of the supply cord is necessary, this has to
be done by Bosch or an authorized Bosch service agent in or-
der to avoid a safety hazard.
If the machine should fail despite the care taken in manufac-
turing and testing procedures, repair should be carried out by
an after-sales service centre for Bosch power tools.
In all correspondence and spare parts order, please always in-
clude the 10-digit article number given on the type plate of
the machine.
