Technical Data
Laminate trimmer
Article number
Rated power input
No-load speed
Tool holder
Weight according to EPTA-Procedure 01/2003
Protection class
The values given are valid for a nominal voltage [U] of 230 V. For different voltages and models for specific countries, these values can vary.
Please observe the article number on the type plate of your machine. The trade names of the individual machines may vary.
Noise/Vibration Information
Measured sound values determined according to EN 60745.
Typically the A-weighted noise levels of the product are:
Sound pressure level 84 dB(A); Sound power level 95 dB(A).
Uncertainty K =3 dB.
Wear hearing protection!
Vibration total values a (triax vector sum) and uncertainty K
h
determined according to EN 60745:
2 2
a =4.5 m/s , K=1.5 m/s .
h
The vibration emission level given in this information sheet
has been measured in accordance with a standardised test
given in EN 60745 and may be used to compare one tool with
another. It may be used for a preliminary assessment of expo-
sure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or poorly maintained,
the vibration emission may differ. This may significantly in-
crease the exposure level over the total working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
nificantly reduce the exposure level over the total working pe-
riod.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep hands warm, organise work patterns.
Declaration of Conformity
We declare under our sole responsibility that the product de-
scribed under "Technical Data" is in conformity with the fol-
lowing standards or standardization documents: EN 60745
according to the provisions of the directives 2011/65/EU,
2004/108/EC, 2006/42/EC.
Technical file (2006/42/EC) at:
Robert Bosch GmbH, PT/ETM9,
D-70745 Leinfelden-Echterdingen
– Unscrew the tightening nut 5 with open-end spanner 15
Bosch Power Tools
Professional
3 601 F0A 1..
W
-1
min
mm
inch
kg
Dr. Egbert Schneider
Senior Vice President
Engineering
Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen
26.10.2011
Assembly
Changing the Tool
Before any work on the machine itself, pull the mains
plug.
It is recommended to wear protective gloves when in-
serting or replacing router bits.
Disassembling the Routing Base (see figure A)
Before a router bit can be inserted, the routing base 2 must
first be removed from the motor unit 1.
– Open the clamping lever 10 and turn the routing base 2 so
that the mark is in line with the
tor unit 1.
– Pull the motor unit upward to the stop.
– Turn the motor unit in anticlockwise direction to the stop
and pull it out of the routing base.
Replacing the Collet (see figure B)
Depending on the routing tool being used, the tightening nut
with the collet 5 may need to be replaced before inserting the
router bit.
When the right collet for your router bit is already mounted,
follow the work steps as described under "Inserting a Router
Bit".
The collet 13 must have somewhat play when seated in the
tightening nut. The tightening nut 5 must assemble easily.
Should the tightening nut or collet be damaged, replace im-
mediately.
– Push the spindle lock button 9 and keep it pressed. If re-
quired, rotate the motor spindle by hand until it locks.
turning in anticlockwise direction.
English | 15
GKF 600 GKF 600
Professional
3 601 F0A 16.
3 601 F0A 17.
600
33000
6/8
–
1.5
/II
Dr. Eckerhard Strötgen
Engineering Director
PT/ESI
symbol on the mo-
2 610 007 835 | (24.11.11)
600
33000
–
¼
1.5
/II
