MACHINE OVERVIEW

1
10
1. FRONT VICE HAND WHEEL
2. LOWER BLADE GUARDS
3. UPPER BLADE GUARD
4. SWIVELLING FRONT VICE JAW
5. ADJUSTABLE REAR VICE JAW
6. HANDLE & TRIGGER SWITCH
3
2
4
5
11
7. MOTOR / CARBON BRUSHES
8. ARBOR LOCK BUTTON
9. DUST EXTRACTION PORT
10. LOCK DOWN CHAIN
11. LEVER HANDLED LOCKING SCREW
12
www.evolutionpowertools.com
6
8
9
7
