Attaching the CENTROTEC
Pull the release ring [5-1] forwards.
Attach the tool chuck to the drill spindle
[4-1].
Release the ring [5-1].
Detaching the CENTROTEC
Pull the release ring [5-1] forwards.
Remove the tool chuck.
Changing tools
To fi t or remove a tool with a CENTROTEC
shank, pull back the orange ring [5-2].
When attaching the tool, rotate until the
hexagon shank engages in the hexagon
holder on the drill spindle.
Release the ring [5-2].
7.3 Angle attachment
The angle attachment allows you to work
(drill, fasten) vertically in relation to the
longitudinal axis on the machine.
Fitting the angle attachment
► Before fi rst use, the spindle [4-1] and
gearbox neck [6-1] should be painted with
a thin layer of multipurpose grease.
Release the lever of the angle attach-
ment.
Fit the attachment right down onto the neck
of the gearbox so that the recess in the at-
tachment sits on the protruding part of the
gearbox.
Secure the attachment lever.
The angle attachment can be positioned
through 30°.
Attaching/Detaching the chuck
The chuck is secured to the shaft of the
angle attachment and the drill spindle on
the machine in the same way.

7.4 Auxiliary handle

Fit the auxiliary handle right down onto the
neck of the gearbox so that the recess in
the handle sits on the protruding part of
the gearbox.
Tighten the auxiliary handle by twisting the
grip.
The auxiliary handle can be positioned
through 30°.
The drilling depth can be set with the depth
stop [7-2].
7.5 Tool holder in the drill
spindle
Bits can be inserted directly in the hexagon
socket holder on the drill spindle [4-1] to
shorten and reduce the weight of the ma-
chine.
8

Operation

Press the ON/OFF switch [1-2] to switch on
the machine.
The speed of the machine depends on how
far the ON/OFF switch is pressed in.
Release the ON/OFF switch [1-2] to stop
the machine.
When the ON/OFF switch is released, the
working spindle (chuck) stops immediately.
Bit store
The bit cartridge can be used to store bits
and bit holders. The magnetic holder can
also be used for screws and similar items.
Clamp for attaching to the belt [1-7; on the
right/left] enables the device to be attached
to work wear for a short-term.
Acoustic warning signal
Acoustic warning signals sound and the ma-
chine switches off in the following operating
states:
- Battery fl at or machine
peep
• Change the battery
• Place the machine under
- Machine is overheating
• You must allow the
peep peep
- LiIon battery pack is
peep peep peep
• Once the battery pack
overloaded
pack.
reduced stress.
machine to cool before
using again.
faulty or has overheated.
has cooled, perform a
functional check using
the charger.
