Table of contents
1 Symbols ................................... 12
2 Machine features ....................... 12
3 Service description ..................... 12
3.1 Product features ........................ 12
3.2 Intended use ............................. 12
4 Safety instructions ..................... 13
4.1 Machine-related safety
instructions ............................... 13
4.2 Emission levels .......................... 13
5 Commissioning .......................... 13
5.1 Changing the battery pack .......... 13
5.2 Charging the battery pack ........... 13
5.3 Charger wall mount .................... 14
6 Settings .................................... 14
6.1 Changing the direction
of rotation ................................. 14
6.2 Changing gear ........................... 14
6.3 Fastening .................................. 14
6.4 Drilling ..................................... 14
7 Tool holder, attachments ............. 14
7.1 Chuck KC 13-½K-FF ................... 14
7.2 Tool chuck CENTROTEC CC-CE ..... 14
7.3 Angle attachment AU-DRP 16 ...... 15
7.4 Auxiliary handle ......................... 15
7.5 Tool holder in drill spindle ............ 15
8 Operation ................................. 15
9 Service and maintenance ............ 16
10 Transport .................................. 16
11 Accessories ............................... 16
12 Disposal.................................... 16
13 Warranty .................................. 17
14 EU Declaration of Conformity ....... 17
1

Symbols

Warning of general danger
Risk of electric shock
Wear ear protection!
Read the instructions
Not to be included in municipal refuse
Advice or tip
►
12
2

Machine features

[1-1] Bit holder
[1-2] ON/OFF switch
[1-3] Right/left switch
[1-4] Gear switch
[1-5] Drilling/Fastening symbols
[1-6] Torque thumbwheel
[1-7] Clamp for attaching to the belt
[2-1] Battery pack
[2-2] Buttons for releasing the battery

[3-1] LED

Not all of the accessories illustrated or de-
scribed are included as standard delivery.
3

Service description

3.1 Product features

Your PROTOOL cordless drill has the follow-
ing product features:
- CENTROTEC and FastFix rapid change
system
- System battery interface and charger for
NiCd/NiMH and LiIon battery pack
- Fully electronic torque selection and shut-
off
- Temperature protection, undervoltage
and overvoltage protection and dynamic
current limiting for protecting the ma-
chine and the battery pack
- Brushless, wear-resistant EC motor

3.2 Intended use

Cordless drills are suitable for drilling into
metal, wood, plastics and similar mate-
rials as well as inserting and tightening
screws.
The BC 3 charger is designed for charging
the battery packs listed.
The user is responsible for any damages
and injuries caused by use which does not
conform to the intended purpose; including
any damages and wear caused by perma-
nent industrial operation.
