5.3 Wall mounting
There are two elongated holes on the back
of the BC 3 for mounting the charger to
a wall using two screws (e.g. round head
or fl at head screw with shank diameter of
5 mm).
Insert the two screws into the wall at a
distance of 96 mm from one another and
leave the screw heads protruding approx.
4 mm.
6 Machine settings
► Setting must be done only when the ma-
chine is turned off and will be accepted
only after restarting it.
6.1 Changing the direction of
rotation
The right/left switch [1-3] changes the di-
rection of rotation.
Move switch from right to left = clockwise
rotation;
Move switch from left to right = anticlock-
wise rotation.

6.2 Changing gear

► Always switch off the machine before
changing gear!
You can change gear using the gear switch
[1-4].

6.3 Fastening

Move the switch [1-6] to the torque setting
[1-5].
Setting on 1
Setting on 12
The machine switches off when the preset
torque is reached and an acoustic signal
sounds. You must release and press the
ON/OFF switch [1-2] again to start the ma-
chine.
Upon levels 1 – 12, a decreased number of
rotations can be set.

6.4 Drilling

The selector switch [1-6] is set to the drill
symbol marking [1-5] = maximum torque.
14
= low torque
= high torque
7 Tool holder,
attachments
7.1 Chuck
The chuck is used for clamping drill and
screwdriver bits.
Attaching the chuck
► Before fi rst use, the spindle [4-1] should
be painted with a thin layer of multipur-
pose grease.
Attach the chuck to the drill spindle [4-1].
Pull the release ring [4-2] forwards.
Turn until the hexagon pinon the chuck en-
gages in the hexagon socket holder in the
drill spindle.
Push the chuck all the way onto the drill
spindle.
Release the ring [4-2].
Detaching the chuck
Pull the release ring [4-2] forwards.
Remove the chuck.
Changing tools
Turn the clamping sleeve [4-3] anticlock-
wise to open the clamping jaws.
The arrow on the chuck shows the direction
to turn to open it.
Insert the tool into the chuck.
CAUTION
Risk of injury
► Clamp the tool centrally in the chuck!
Turn the clamping sleeve [4-3] clockwise
to clamp the tool.
7.2 Tool chuck CENTROTEC
The tool chuck CENTROTEC allows you to
change tools with a CENTROTEC shank in
a matter of seconds.
► Always use a CENTROTEC tool chuck to
clamp CENTROTEC tools.
CAUTION
Risk of cutting injuries when changing
the tool!
► Wear protective gloves!
