DISPLAY-MODE

display function
LITECRAFT LITECRAFT
SW.V *.* SW.V *.*
DEF. SET DEF. SET
<***>
*** =
<NO>
<YES>
DispPerm DispPerm
<***>
*** =
<On>
>Off>
DMX-1CH DMX-1CH
DMX *** =
< DMX-adress
DMX-2CH DMX-2CH
DMX *** =
< DMX-adress
DMX-3CH DMX-3CH
DMX *** =
< DMX-adress
DMX-4CH DMX-4CH
DMX *** =
< DMX-adress
DMX-8CH DMX-8CH
DMX *** =
< DMX-adress
ColMacro ColMacro
<Macro **>
** = <black-43>
ColProgr ColProgr
<Prog **>
** = <1-8>
ColSpeed
<**>
** =
<1-16>
ColSet ColSet
Shows the software-version direct after
switching on the unit
*.* = software-version
(this menu dissaperars automaticly
after 3 seconds)
reset all parameter to factory defaults
(this menu dissaperars automaticly
after 5 s)
(default setting = DMX-4CH, Adresse
001)
setting automatic switch off for lcd
backlite (display switches off
automaticly after 10 s and will be
activated by pressing one off the
buttons for at least 3 s)
(default setting = On)
setting DMX-channel mode 1
(description of modes in next chart)
setting DMX-channel mode 2
(description of modes in next chart)
setting DMX-channel mode 3
(description of modes in next chart)
setting DMX-channel mode 4
(description of modes in next chart)
(default setting = DMX-4CH)
setting DMX-channel mode 8
(description of modes in next chart)
choose one of 43 pre-programmed
colors + black
choose of 8 pre-programmed chasers
choose speed in 16 steps for pre-
programmed chasers
setting brightness for each color in
