TREND FAST TRACK MK2 Übersetzung Der Originalanleitung Seite 4

trend
tool technology
EN - FTS/KlT/MK2
Thank you for purchasing the FTS MK2.
The following symbol is used throughout
instructions.
• Denotes risk of personal injury, loss of life or
damage to the tool in case of non-observance
instructions.
INTENDED USE
This accessory is intended to raise and maintain the
cutting edge of hand chisels and plane irons.
SAFETY
PLEASE KEEP THESE INSTRUCTIONS
PLACE.
Users must be competent in using woodworking
equipment before using our products.
gloves, safety glasses and dust mask. Consider working
environment before using tools. Ensure working position
is comfortable and component
Please keep children and visitors away from tools
and work area. All tools have a residual
therefore be handled with caution. All cutting edges are
very sharp and care must be taken to prevent injury.
Never sharpen blades towards the hand or body. Always
work in a clear uncluttered area.
ITEMS REQUIRED
• Light lubricant oil
• Pozi@ NO.2 screwdriver.
DESCRIPTION OF PARTS • (Fig. 1)
A. Base
B. Centring clip xl
C. Shoulder x2
D. Carriage
E. Taper prep stone 220# (Black) xl
F. Taper finishing stone 450# (White) xl
Mounting screw No.8 x 1-1/4" xl
G.
H. Cleaning block xl
. Non slip mat xl
Optional Accessories
(Included with FTS Complete
J. Storage case
K. DeBurr plate, fitted to tool recess
L. Strop, fitted to underside of base
M. Taper roughing stone 100# grit (White)
N. Taper fine finishing stone 600# grit (Red)
O. Taper super fine stone 1000# grit (Green)
these
of the
IN A SAFE
Please wear
is clamped securely.
risk, so must
Set)
EN - FTSMK2
OPERATION
• Check the point of contact between diamond stone
and blade edge
Centring Clip - (Fig.
• Clip on to centre small chisels
• Remove for plane Blades
Sharpening Angles
• The FTS has four sharpening angles.
Angle 1 = 250 Angle 2 = 27 1/20AngIe 3 = 300
Angle 4 = 32 1/20
• To maximise the number of tool re sharpens start
sharpening at the lowest angle number possible.
• We estimate 24+ individual re-sharpens
primary re-grinds
What Angle Do
Angle - (Fig. 3)
• Fit the stone to the carriage so that the stone taper
matches the sticker.
• Slide carriage onto the base with wing 1 / 3 towards
the tool recess
• Note: Repeatthe same procedureto achieve
any of the 4 Angles
Before Sharpening
• Check the point of contact between diamond stone
and blade edge
• Goto sharpeningset-up - (Fig. 4a)
• Try next AngleSetting - (Fig. 4b)
Note: If your blade looks like B, evenat angle
setting 4, or if the blade is badly damaged. the tool will
need a primary re grind.
Primary Re-grind
• Remove material as shown
• Re establish bevel just below 250
Note: We recommendusing a powered
grinding wheel for this. It is possible to primary re-grind
using FTS and 100# Grit Extra Coarse Stone (accessory)
however, the wider the blade the more
remove, the longer it will take.
-4-
2)
and Angle Settings
between
Start At? Set-up
• (Fig. 5)
in black
material to
