Battery Connection
1. For NiCd/NiMH: Plug the adapter into the charger FIRST. Then connect the battery to
the adapter ONLY after it has been connected to the charger.
Proceed to the "Starting Charge" section.
2. For LiPo, Li-Ion or LiFe: Lithium batteries for R/C are commonly available in two
different assembly/wiring configurations: wired for balancing and non-balanced.
It's important to know which configuaration you have before proceeding.
Consult your battery supplier if you are unsure if your battery is wired for balancing,
if it is not wired for balancing but has a built-in safety circuit, or neither.
WARNING! It is NOT recommended to charge a LiPo battery which is not wired for
balancing. Such types of LiPo have NO means to protect the equipment or the user from
damage that could result from an overcharge condition of any cell in the pack.
NON-BALANCED packs are wired so the charger can only detect the voltage of
the entire pack (not individual cells), so there is only one charge lead. It's highly
recommended to ONLY use such types of LiPo packs if they have a built-in charge
safety circuit which prevents any single cell in the pack from being overcharged.
Simply connect the battery's main power lead to the charger's banana jacks
(noting correct polarity).
The image to the right shows the
LiPo set up with the balance board
Balance Port
Balance Board
Output
- 8 -
LiPo
