The display mode on the receiver will show the reception level for each of the registered transmitter(s). Please note that, in this
mode, the contact status display and the buzzer will no longer function, but the relay outputs will continue to operate normally.
Each registered TX has a rank: the first registered TX will be rank 1, the second rank 2, etc.
Activating display mode on the RX module
Press the PROG.RX button.
1
LED 4 will flash slowly in accordance with the TX module
2
Slow flashing
*TX module reception level in relation to number of flashes:
Number of flashes
Reception level
Range
The display mode on the transmitter will show pairing status in the receiver memory.
Activating display mode on transmitter (TX)
Press the PROG.TX button.
1
If the transmitter is not paired
2
If the transmitter is paired
3
Transmitter (TX) indicator lights:
In nominal mode (= transmitter (TX) paired with a receiver (RX))
If the transmitter (TX) is paired with a
868Mhz radio bridge
☛
⏱>1 s
number.
✕
TX rank number
0 1
No reception
Very weak
Insufficient range
☛
⏱>1 s
receiver (RX).
LED 4 will flash rapidly ~5 times.
LED 1 will flash in accordance with the reception level of
Flashing
2 3
Weak Medium
Medium range
The transmitter LED will flash rapidly.
The transmitter LED will flash slowly.
The number of flashes indicates the TX rank
Slow flashing
The transmitter LED will light up
briefly with each change in the
status of inputs B1 and B2.
15
ISTCO7SG-KIT_EU_1224
5
✕ fast
the TX module*.
✕
Reception level
4
Good
OK range
Rapid flashing
number in RX memory.
Rank number of
✕ the registered
TX module
5
Very good
