2.5 Operating conditions

i
Temperature range during operation: 0 to +50°C
Relative air humidity: 95% at +10°C not condensed

3.1 Settings and adjustments

!
The machine may only be operated with the flange head!
Locking button
Safety lever
ON/OFF handle
EN
Recommended user supply: Min. 25
CFM | 0.71 m3/min
Air pressure: max 6.3 bar / 91 PSI
4
Mounting a bevel head:
Push the locking button to lock
the spindle. Place bevel head and
fasten guide guide bearing tight
with 6 mm Hex wrench.
Rotate flange head clockwise
or counterclockwise to adjust
depth.
1 click is 0,125 mm up or down.
Fiting 1/4"
High flow fittings recommended
