Maintenance
Cleaning the stylus:
(Refer to 8 on page 3)
If dust or grime builds up on the stylus tip, clean it using the included
stylus cleaning brush.
Always brush the stylus from rear to front (in the direction the record
spins).
Replacing the stylus
A worn stylus not only reduces sound quality, but may also damage
your records.
As a general guideline, we recommend replacing the stylus after
approximately 400 hours of use.
Before replacing the stylus:
ū Disconnect the AC adapter from the power outlet.
ū Hold the headshell and cartridge body firmly during removal and
installation.
To remove the old stylus:
(Refer to 9 on page 3)
Rotate the front of the stylus downward and forward to detach it.
Installing a new stylus:
(Refer to 10 on page 3)
Mount the replacement stylus onto the cartridge.
(Refer to 11 on page 3)
Gently lift the stylus until you hear a click.
(Refer to 12 on page 3)
Ensure there is no visible gap between the headshell and the cartridge.
Replacing the drive belt:
Over time, the drive belt may wear out or break. Replace it with a new
belt when needed.
There is a spare drive belt included with the unit.
To replace the drive belt:
1. Turn off the turntable and any connected audio devices.
2. Unplug the AC adaptor from the power outlet.
3. Remove the rubber mat from the platter.
(Refer to 13 on page 3)
4. Unhook the existing drive belt from the motor pulley.
Insert your fingers through the round holes in the platter to grip it, then
lift to remove the platter.
(Refer to 14 on page 3)
5. Turn the platter upside down and remove the old drive belt.
6. Fit the new drive belt around the inner rim of the platter, ensuring it
remains flat and untwisted.
To reassemble the unit, follow the steps in the "Assembling the
turntable" section.
Recording to PC
You can record the audio from your vinyl records to a computer using
the USB port (type C) connection on your turntable and compatible
audio recording software.
What You'll Need
ū A computer or laptop with a USB port
ū Audio recording software installed on your computer (not
supplied)*
ū A USB data cable
*Many third-party audio recording applications are available online.
For example, software like Audacity is commonly used for this purpose.
Sharp Consumer Electronics is not affiliated with or endorsed by its
developers.
Connecting the Turntable to Your Computer
Plug the USB cable into the USB port (type C) on the back of the
turntable.
Connect the other end of the cable to an available USB port on your
computer.
Turn on the turntable using the
Your computer should automatically recognise the turntable as an audio
input device. It may appear as USB PnP Audio Device or a similar name,
depending on your operating system.
Recording Setup in Software
Open your chosen audio recording software.
Go to the audio input or recording device settings.
Select the USB input device associated with the turntable (often listed
as "USB PnP Audio Device").
Set the recording input to stereo for full-channel recording (if
applicable).
Adjust the sample rate or other recording preferences as required by
your software.
Start Recording
ū Place a vinyl record on the platter and begin playback using the
button.
ū Press the Record button in your software to begin capturing the
audio.
ū When finished, stop the recording and save the file in your prefer-
red format (e.g. WAV, MP3).
Troubleshooting
Vinyl record playback
The tonearm skips or skates.
ū The turntable is not level. Place it on a stable, level surface.
ū The vinyl record is dusty or scratched. Clean it with a commercial
record cleaning product or replace the record.
Upon playback, the stylus drops off the edge of the record.
1. Press and hold the
button for at least 6 seconds. The tonearm will
return to the tonearm rest, and the platter will stop.
2. Press play. The stylus will move from outside the record inward,
towards the correct starting drop point.
3. You can repeat steps 1 and 2 up to 3 times to fine-tune the position
by increments of 2 seconds.
Upon playback, the stylus lands too far into the record.
1. Press and hold the
button for at least 6 seconds. The tonearm will
return to the tonearm rest, and the platter will stop.
2. Press play. The stylus will move from the inside of the record
outward, closer to the correct starting drop point.
3. You can repeat steps 1 to 3 up to 3 times to fine-tune the position by
increments of 2 seconds.
Upon playback, the stylus is not at the default starting position.
ū Press and hold the button for at least 6 seconds. This resets the
stylus to its factory-set default starting position.
You experience sound problems.
ū If the stylus is dirty, clean it using a stylus cleaning brush or
cleaning fluid.
ū If the stylus is worn out, replace it with a new one.
ū If sound pitch is unstable, the drive belt may be worn or twisted.
Inspect the belt and replace if necessary.
ū If the vinyl record is dusty, clean it using a commercial record
cleaner.
You hear rumbling or low-frequency howling.
ū The turntable is too close to your speakers. Move it further away to
avoid feedback or resonance.
