Sharp RP-TT95 Bedienungsanleitung Seite 8

7
A. If the external audio device has a PHONO input jack (connected to
the PHONO input jack) Set the PREAMP switch to PHONO.
In this configuration, an audio signal from the cartridge bypasses the
turntable's built-in preamp. The external device is used instead.
B. If the audio device does not have a PHONO input jack, set the
PREAMP switch to LINE.
In this configuration, an audio signal from the cartridge uses the
turntable's built-in preamp.
NOTE:
ū Ensure the RCA plugs are inserted firmly into their respective jacks. Loose
connections may cause noise, drop-outs, or degraded audio quality.
ū If using the included RCA cable w/grounding, connect the cable to GND
on the unit. Connect the other end to the external device. Alternatively,
you can use your preferred RCA and grounding cable
3. Connect the AC adapter.
(Refer to 6 on page 2)
NOTE:
ū To avoid noise interference, place the AC adaptor body away from your
turntable as far as possible.
NOTES:
ū If you're using Bluetooth only and have disconnected the RCA audio cable
from your external device, make sure the metal tips of the cable do not
touch each other or any metal surfaces (such as racks or casing). To use
the turntable in Bluetooth mode, set the PREAMP switch to LINE.
ū If you connect the RCA cable to a PHONO input but leave the PREAMP
switch set to LINE, the output may be extremely loud and could damage
your amplifier or speakers.
Always set the switch to PHONO when using a PHONO input.
ū If you connect the RCA cable to an analogue input (such as AUX or LINE
IN) but set the PREAMP switch to PHONO, the output will be very quiet.
Always set the switch to LINE when using a standard analogue input.
Bluetooth operation
When connecting your turntable to a Bluetooth playback device for the
first time, allow up to one minute for the connection process. Please
ensure you turn your speakers on first before starting the connection
process.
1. Place the playback device (that supports Bluetooth wireless
technology) as close as possible to the turntable.
2. Press the button on the unit or the remote control to enter
Bluetooth pairing mode.
The button on the unit will light up white and begin flashing
while pairing.
3. Activate pairing mode on the Bluetooth playback device you wish to
connect. Once the connection is successful, the
flashing and remain steadily lit.
ū If the playback device is already connected to another source (such
as a phone or computer), disconnect or unpair it from that device
before attempting to connect to the turntable.
NOTE:
ū If you are only using the Bluetooth connection and not connecting the
turntable to another device using the RCA audio cable, set the PREAMP
switch on the back of the turntable to LINE.
4. To disconnect from the paired device, press the
unit or the remote control.
If you cannot pair devices
ū If multiple Bluetooth-enabled playback devices are nearby, some
may connect automatically even if they are not the intended de-
vice. Disable Bluetooth on those devices and try pairing again.
ū If an unintended device connects during pairing, adjust that
device's settings to prevent automatic Bluetooth wake-up, or turn it
off and retry pairing.
Listening to a vinyl record
Follow these steps to play a vinyl record using your turntable.
If this is your first time playing a vinyl, make sure you have initialised
your turntable by following the steps in step 5 of section "Assembling
the turntable".
1. Place a vinyl record on the platter.
To play a 7-inch (17 cm) vinyl record (EP), place the supplied 45 RPM
adapter on the spindle.
2. Select the rotation speed.
Press the
and 45 RPM.
The corresponding indicator will light up..
3. Select the record size.
Press the
12-inch record sizes.
The corresponding indicator will light up.
4. Remove the stylus protective cover.
5. Press the
The tonearm will automatically descend to the correct starting
position (based on the selected size), and playback will begin.
6. Adjust the volume using your connected audio device.
Stopping or Pausing Playback
ū To stop playback, press the
the tonearm rest, and the platter will stop.
ū To pause playback, press the
the record, but the platter will continue spinning.
ū When playback reaches the end, the tonearm will return to the
tonearm rest automatically, and the platter will stop rotating.
Repeat Playback
Press the
ū When repeat mode is active, the record will automatically replay
from the beginning after playback ends.
ū The backlight of the REPEAT icon will light up white while repeat
mode is active.
Fast Forward and Rewind
ū Turn the
step to the left or right.
ū Short press the
the tonearm one step in the desired direction.
ū To move the tonearm continuously, hold the knob in the desired
direction, or press and hold the corresponding button on the
remote control. The tonearm will remain raised while moving and
lower again once movement stops.
button will stop
NOTE:
ū When the tonearm reaches the end of the record, it will automatically
return to the tonearm rest.
Gain Select
Adjust the
played.
If the record is recorded quietly, set volume adjustment to HIGH.
If the record is recorded loudly, HIGH setting may cause distortion.
Select volume setting appropriate to the record for correct playback
button on the
level.
Gain settings only affect output when the PREAMP switch is set to LINE,
or when using Bluetooth.
They do not affect audio output when the PREAMP switch is set to
PHONO.
button on the unit to toggle between 331/3 RPM
button on the unit to choose between 7-inch and
button on the unit or remote control.
button. The tonearm will return to
button. The tonearm will lift from
button to toggle repeat mode on or off.
/ knob on the unit once to move the tonearm one
or button on the remote control to move
switch to suit the volume level of the record being
