Kinetec Data Capture Benutzerhandbuch Seite 29

No USB key connected to the computer
Generate patient report - no USB key connected
Setting the date and time
The date and time used by the KINETEC DATA CAPTURE™ software are managed in the hand controller of your
passive mobilisation appliance.
We recommend that you regularly check that they are correct.
The procedure for setting the date and time is the same for knee and shoulder appliances. No USB keys are
required.
Start
Switch the appliance off
Press both buttons at the same time
and switch on
The day blinks
Change the day if necessary
Confirm and proceed to change the
month and so on for the other areas
Or for global confirmation
If the date and time are set to 01/01/00 00:00 after switching the appliance off, change the battery of the hand
controller.
KINETEC DATA CAPTURE™
The software functions are limited. You are only able to
generate patient reports using data already stored on the
computer (see page 9).
Click the patient report button on the main screen.
A window opens allowing you to select the saved data.
Select the patient and click OK.
The report is displayed; see page 10 for more details.
Press buttons
and
or
SPECTRA VXX.X
EN
Display
Check that the controller
isn't blocked (see appliance
manual).
20/10/12
The factory-set date and
time are displayed.
15:22:35
The date is in the format
DD/MM/YY
The time is in the format
HH:MM:SS
20/10/12
15:22:35
25/10/12
The new day blinks.
15:22:35
25/10/12
The month blinks.
15:22:35
KINETEC
Exit "change date and time"
mode and return to normal
use of the controller.
Comments
11/14
