Generate patient report
On the main screen, click the Patient report button (See page 6).
The displayed report is generated from data stored on the USB key. To generate patient reports
without a USB key, see page 11.
Note:
The report will includes all sessions stored under the same patient name.
If the patient carried out 2 sessions, the report will only contain 2 columns. If the patient has
carried out 45 sessions, the report will contain 45 columns. One column corresponds to one
session.
2 reports are available and correspond to the type of appliance used: knee appliance or
shoulder appliance.
Patient report for the knee appliance





Patient report for the shoulder appliance






KINETEC DATA CAPTURE™



generated







Notes: When the arrow hovers over a session bar (without
clicking it), a message is displayed with all the information
concerning the work session.
Clicking a session bar displays the sessions for the week.
Clicking a second time displays the sessions for the day.
Clicking a third time returns to the overall view.

EN
Patient name
Total time of passive mobilisation and date report
Range of motion per session graph
Knee range of motion
Abduction motor range
Rotation motor range
Session time graph
Details button:
to display treatment session averages
Print the patient report: the reports are printed on
the default Windows printer
Exit the patient report display and return to the main
screen
10/14
