Program management


 Preselect a program for removal
Validate the program list and return to the main screen

Erase preselected programs

 Undo changes and return to the main screen
 Print the programs saved on the USB key: the programs are printed on the default Windows printer
Possible movements:
-
With a USB key formatted for knees:
"Kinetec" or "Warm Up" movement
The Limit Ext 1 and Limit Flex 2 columns are not available.
-
With a USB key formatted for shoulders:
Abduction or Flexion/Extension or Rotation or Abduction + Rotation
or Horizontal Abduction movement,
The Limit Ext 2 and Limit Flex 2 columns are only available for the Abduction + Rotation
movement.
Note:
- Up to 16 programs can be stored.
- When connecting the USB key to the KINETEC
are visible. Programs that have already been stored on the controller cannot be accessed but remain in
memory.
- It is possible to move the cursor from one field to another using the Tab key.
- When pressing the Cancel button, the following dialogue box is displayed:
KINETEC DATA CAPTURE™




-> Click Yes to return to the main screen (modifications will be lost).
-> Click No to return to the patient list.
This function is only available if a USB key is
connected.
Click the "Program" icon to access it.
When this function is used for the first time, or after

formatting the USB key, no programs are available.
Program parameters input area


Preselect all programs for removal
 Unselected program
 Selected program
®
appliance hand controller, only the programs on the key
EN 7/14
