Front fork

1
2
3
End of front fork
Attach the Handle Bar │ 6
Remove the M5x35 machine screw and
end of the front fork. Turn the vehicle body upright.
1. Insert the front fork into the opening on the front of the
vehicle body from the bottom side, and out through the
hole on the top of the vehicle.
2. Place the handle bar over the the end of the fork.
4
3. Align the holes on each side of handle
bar with the holes at the end of the
fork.
4. Fasten a nut on the opposite end of
the screw to secure the handle bar.
nut from the
Ø5
