Use
Changing the batteries from the LED-light:
WARNING!
!
Please note the safety instructions for the LED-light and batteries!
1
Remove the LED light
from the walker. Rotate
the top of the LED
housing right round so it
loosens and remove it.
Folding the rollator:
1
Austausch Bremsblock:
1
26
PUSH
B
B
A
2
Now push the light (A)
out of the housing and
remove the two batteries
(B). Pay attention to a
professional disposal.
2
2x lithium button cell CR 2032, 3V each
C
C
PUSH
2.
1.
3.
3
1. Insert the new batte-
ries (C). Pay attention to
the polarity.
2. Then insert the lamp
back into the housing and
3. close it.
1
so that the seat disengages from the
bracket and the rollator contracts.
Then use the clamp to lock it to the
seat tubes.
2
height to the lowest level to save
even more space.
3
the handle bar.
3
1
brake (16) upwards to release it
release it from the anchorage.
Then pull the tab backwards to
remove the entire brake block.
the entire brake block.
2
completely into the bracket
bracket until it clicks.
4
Now you can attach the
light to the walker again
as described.
Pull the seat up on the grip tab
If necessary, set the handle
Transport the folded rollator using
Pull the tab of the
Insert the new brake block
