VEVOR 9466 Installation

Model: 9466
6inch Mechanic Bench Vise
Warning-To reduce the risk of injury, user
must read instructions manual carefully.
NEED HELP? CONTACT US!
Have product questions? Need technical support? Please
feel free to contact us:
Technical Support and E-Warranty Certificate
www.vevor.com/support
This is the original instruction, please read all manual instructions carefully before
operating. VEVOR reserves a clear interpretation of our user manual. The
appearance of the product shall be subject to the product you received. Please
forgive us that we won't inform you again if there are any technology or software
updates on our product.
01
SPECIFICATIONS
Model： 9466
Designation： 6inchMechanicBenchVise
Material: DuctileIron
Overallsize: 440*175*235mm
Baking width: 151mm
Maximum opening: 130mm
Maximum clamping force: 30KN
Color: Blue
Weight: About19.1kg
Solid Ductile iron
Rotation table 360° rotation
Suitable for installation on the table.
PACKAGE
1 x Bench Vise Table Top Clamp Press
1 x User Manual
4 x Nuts
4 x Screws
APPLICATION
Bench vice is used to clamp workpieces. It is installed
on the work stations to clamp the workpieces. It is an
necessary tool in the schlosserei. Rotating disc type
clamp body can revolve so that make the workpiece
rotate to the suitable place. Most work of fitter are fini-
shed on the bench vice. For example, the saw, the file,
the chisel and components installing and dismantling.
02
INSTALLATION
Install the pliers on the clamp table
1、 Operating instruction
The height of operator working will be suitable because
the bench vice is installed on the workbench. Usually
the jaw height is flushed with elbow just right. This is ok.
Put the elbow on the bench vice peak and half
clenched fists
that the fist just support the mandible. Length and
width of work bench will be decided by the work.
2、 Cautions
（1）Appropriate degree of tightness when clamp the
workpiece. Just tight the handshank by the hand only.
Do not add strength with the help of other tools. No
clamp-holding force shall be exceeded .
（2）When work strongly, you need try your best to
make strength facing to clamp body.
（3）Do not knocking on the clamp body and smooth
surface.
（4）Clean and lubricate the surface of lead screw
and nut so that it will not rust.
