1 x long, 2 The wireless
x short red remote control
flashes is defective
1 x long and Duty Cycle
1 x short red
flash
Slow green Configuration
flashing mode (device
waiting for wire-
less)
Slow orange Teach-in mode
flashing (device waiting
for wireless
partner)
Fast orange Configuration or
flashing teach-in mode
(data being re-
ceived)
60
Please contact
your specialist
dealer.
See Section 9.3
„Duty cycle ex-
ceeded".
Wait until the
configuration
data has been
sent.
Switch the de-
vice to be taught
in to teach-in
mode.
Wait until the
process is com-
plete.
LED flashing Stage before
red slowly resetting to fac-
tory settings
Orange LED lights up
flashing with orange throug-
short button hout the dura-
press or but- tion of wireless
ton pressed transmission.
and held Once wireless
transmission
is successfully
complete, the
LED lights up
green for 1 s.
If transmission
was not suc-
cessful, it lights
up red for 2 s.
Device is waiting
for teach-in
button to be
pressed and
held in order to
carry out a reset,
or for a short
button press to
cancel the pro-
cess.
If transmission
was not suc-
cessful, please
try again.
