Operation

After teach-in has been performed, several operator
functions are available for use:
Universal (HM-RC-4-2):
Once you have taught the wireless remote control in
to one or more receivers individually, you can control
these easily using two pairs of buttons (BP 1 and BP
2). The buttons in the pair represent a single unit for
the device you wish to control using the wireless re-
mote control.
For example, you can use the first button pair (BP
1) to switch a lighting actuator on or off, and use the
second button pair (BP 2) to move shutter actuators
up or down.
BP 1
BP 2
54
Alarm function (HM-RC-Sec4-2):
Once you have taught-in the wireless remote control
to your HomeMatic CCU, you can control the alarm
functions easily using a button pair (BP 1) and two
HM-RC-4-2_130816.pdf 1 20.08.2013 10:32:42
individual buttons (B 3 and B 4). The buttons in the
pair represent a single unit for the device you wish to
control using the wireless remote control.
You can use the button pair (BP 1) to arm the alarm
functions if you are either in the house (internal) or not
in the house (external). You can use the individual but-
tons (B 3 and B 4) to disarm the alarm functions unit
and switch the light on or off.
The remote control can not be used in connec-
tion with the HomeMatic Wireless Alarm Con-
trol Unit (HM-Sec-Cen-B).
BP 1
B 3
B 4
C
M
Y
CM
MY
CY
55
