Configuring newly taught-in devices:
Once you have taught your device in to the HomeMa-
tic central control unit, it will be moved to the inbox.
Here, you must configure the device and its associated
channels in order to make them available for operating
and configuration tasks. Give the device a name and
assign it to a room. You can also make individual para-
meter settings.
Now you can use the „WebUI" user interface to control
your device, configure it, link it directly to other de-
vices, or use it in central control unit programs. Please
refer to the „WebUI" operating manual for more details
(you can find this in the „Downloads" area of the web-
site www.HomeMatic.com).
52
Overview of flashing codes during the teach-in
process:
LED flashing codes
1 s green LED
2 s red LED
Slow orange flashing
Fast orange flashing
followed by 1 s green or
2 s red light (depending
on whether process was
successful)
Wireless remote control
in configuration mode
(slow green flashing)
and red light if button is
pressed
Meaning
Teach-in successful.
Teach-in failed. Try
again.
Only the wireless remo-
te control is in teach-in
mode. Switch the device
to be taught in to teach-
in mode as well.
Both devices are in
teach-in mode; teach-in
process taking place.
Wireless remote control
already taught in to cen-
tral control unit and the-
refore blocked for direct
teach-in (see „Teaching
directly in to HomeMatic
devices" section).
