Staircase lighting function with prewarning
Light control
1
2min
Basic function of light control
ON DIP
10s
(Only in combination with dimmable inserts)
30min
1 2 3 4
Light control keeps the lighting in the room at a constant
Test
brightness. The sensor module permanently measures
the brightness in the room and keeps it at an adjustable
setpoint. When movement is detected, the insert initially
A
dims the lighting to the setpoint value. If the ambient
t
brightness changes, the insert dims the lighting accord-
ingly. If sufficient natural light is available, the sensor
B
module will switch the lighting off even if a person is
present.
t
C
D
Example to illustrate light control:
A Switching with prewarning
lx
B Dimming with prewarning
C Overshoot time
A
D Prewarning time (30 s, not adjustable)
The prewarning only applies to channel 1.
|
B
C
Setting the overshoot time for channel 2
A Setpoint
When using a 2-gang insert, the overshoot time for chan-
nel 2 can be adjusted using a separate potentiometer.
B Ambient brightness
The adjustable time period differs from that of channel 1.
C Lighting switched off
D Start phase
1
1h
E Control phase
F Control range
5min
2h
G Prewarning
OFF
H Lighting switched off
Activating/deactivating the presence
function
In the case of a 2-gang insert, the behaviour of the
|
light control is the same for both channels.
In the case of brightness-dependent movement detec-
tion, the sensor module constantly monitors the bright-
ness in the room and compares it to the set brightness
threshold. If sufficient natural light is available, the sen-
Adjusting the light control
sor module will switch the lighting off even if a person is
As soon as the light control is activated via DIP switch 4,
present.
the other DIP switches take on a new or additional func-
The sensor module's presence function is activated as a
tion:
factory default. You can deactivate the function ("OFF")
and reactivate it ("ON") using DIP switch 1.
ON DIP
DIP 1 Response speed
Setpoint change
1 2 3 4
When the presence function has been deactivated, the
sensor module continues to carry out the movement de-
DIP 2
tector function.
24-h staircase light-
ing circuit via PL
Adjusting the 24-h staircase lighting cir-
DIP 3 Adjust start phase 50% bright-
cuit
DIP switch 2 can be used to set a 24-hour staircase light-
ing circuit which you can retrieve from another location
via PlusLink.
The following options are available for this:
• DIP 2 "ON": only switch on the staircase lighting for
24 h via PL
• DIP 2 "OFF": switch the staircase lighting on/off for
24 h via PL
ON DIP
1 2 3 4
Activating/deactivating light control
(Only in combination with dimmable inserts, see function
overview)
The sensor module's light control is deactivated as a fac-
tory default. You can activate the function ("ON") and de-
activate it ("OFF") using DIP switch 4.
ON DIP
1 2 3 4
Adjusting the response speed
The speed with which the sensor module adjusts the
light to the setpoint value can be adjusted using DIP
switch 1.
lx
ON DIP
1 2 3 4
A slow light control
lx
F
ON DIP
1 2 3 4
B fast light control
D
E
G
H
Changing the setpoint
The setpoint is a desired brightness value that should be
observed constantly in the room. This value results from
the ambient brightness and the lighting.
You can select whether or not the setpoint value may be
altered using DIP switch 2. This is possible via the IR re-
mote control or via a push-button module on the central
unit insert.
The brightness of the lighting alters accordingly for set-
point changes.
ON DIP
A
1 2 3 4
ON DIP
B
7
8
9
1 2 3 4
10
lx
Pos. ON (up-
Pos. OFF
per)
(lower)
C
Slow
Fast
Disabled
Via IR re-
mote control
or push-but-
ton module
A Setpoint change disabled
24 h "ON"
24 h "ON" or
B Setpoint change enabled via IR remote control or
24 h "OFF"
via push-button module on central unit insert
Setpoint
C Change setpoint
ness of the
– via IR remote control:
lighting
Push-button 8: Increase setpoint
Push-button 9: Reduce setpoint
– via push-button module:
Upper push-button: Increase setpoint
Lower push-button: Reduce setpoint
Adjusting the start phase
The start phase with which the sensor module switches
on the light can be adjusted using DIP switch 3.
Start at 50% brightness of the lighting
lx
A
A
ON DIP
B
C
1 2 3 4
D
t
E
F
A max. overall brightness (ambient brightness and
lighting)
B setpoint
C 50% brightness of the lighting
B
D ambient brightness
E lighting switched off
F start phase
G control phase
t
Start with setpoint
lx
A
ON DIP
1 2 3 4
B
C
D
A setpoint
B ambient brightness
C lighting switched off
D start phase
E control phase
Operating sensor module by IR remote
control
6
5
4
3
2
You can toggle between three functions of the sensor
1
module by pressing key 10 on the IR remote control B.
A
t
B
Auto
• Auto function: The sensor module is in automatic
mode and switches the loads on when movement is
detected and then off again after the overshoot time
has elapsed.
• 24 h "ON": Load is switched on permanently for 24 h
(no movement detection). Green LED A lights up.
• 24 h "OFF": Load is switched off permanently for 24 h
(no movement detection). Green LED A lights up.
Controlling the sensor module from
another location
Controlling loads from another location
via PlusLink with:
• Push-button module on central unit insert
• Sensor module on central unit insert
• Side controller Plus, 1-gang/2-gang
• Mechanical push-button
t
G
Example of global control with push-button module
on central unit insert
Starting the staircase lighting function
When the push-button module on the central unit insert
A is actuated, all local sensor modules B in the PL
lines start the set staircase lighting function independ-
ently of brightness.
A
PL1
PL2
PL3
PL4
B
E
t
B
A Push-button module on central unit insert (alterna-
tively: side controller Plus for one PL line)
B Sensor module in PL line
24-h staircase lighting circuit
• Upper left push-button: switch on the staircase lighting
for 24 h
• Lower left push-button: switch off the staircase lighting
for 24 h (prerequisite: DIP2 "OFF")
If DIP 2 is switched to "ON", the lighting cannot be
|
switched off for 24 h via the push-button module.
• Upper/lower right push-button: deactivate the 24-h
staircase lighting circuit.
A
ON
OFF
Auto ...
24 h
24 h
PL1
PL2
PL3
PL4
B
B
A Push-button module on central unit insert (alterna-
tively: side controller Plus for one PL line)
B Sensor module in PL line
Example of global control with mechanical push-
button
When the mechanical push-button A is actuated, all lo-
cal sensor modules B in the PL lines start the set stair-
case lighting function independently of brightness.
A
PL
B
B
A Mechanical push-button
B Sensor module in PL line
Example of global control with panic button on the
central unit insert
When the panic button B is actuated, all local sensor
modules C in the PL lines start a fixed overshoot time of
30 minutes (panic scene) independently of brightness.
When a push-button module is used on the cen-
|
tral unit insert, the function can be stopped early.
Press the right push-button in order to do this.
When the central unit insert is used in combina-
tion with a sensor module, the panic function is
not available.
A
B
PL1
PL2
PL3
PL4
C
30 min
C
A Push-button module on central unit insert
B Mechanical push-button (panic button)
C Sensor module in PL line
24 h
