SIP 50000250 Handbuch Seite 15

Sensor point setting
Set sensor point to 06P.
Hold the button down for 3 seconds to
move to the digit you want to set.
Press button once to choose the correct
setting.
The setting range: 01P-20P.
NOTE!
The sensor point setting is changed from
01P to 06P.
Press the button for 3 seconds to return
to the ADJ 3 screen.
Press the button once to enter the ADJ 4
menu (RPM pulse setting).
RPM pulse setting
Press the button once to enter the ADJ 5
menu (Backlight brightness).
Backlight brightness
Press the button once to enter the ADJ 6
menu (Total mileage).
Total mileage
Press button once to enter the ADJ 7
menu (Adjustable mileage).
Adjustable mileage
Press button once to return to the main
display.
Main display
4.2
TRANSMISSION AND SPEEDO DRIVE
The table below shows some original data for your reference - make sure to
check components, respective number of teeth.
Transmission (examples)
Vespa 125 GT/GTR/Super/TS/150
T4/GL/GS/ Sprint/V/Super/Rally/P150S
Vespa 125 GT/GTR/Super/TS/150
T4/GL/GS/Sprint/V/Super/Rally/P150S
Vespa 125 GT/GTR/Super/TS/150
T4/GL/GS/ Sprint/V/Super/Rally/P150S
Vespa 50/PV/ET3/PK50/S/SS/XL
Vespa PK50-125 S/XL/2/HP/N/PK125/
ETS
Vespa P80-150X/PX80-150E/PX80 E
Lusso/P200E/MY/P200E/T5/Cosa
Vespa PX100-200E/PX125-150 E
Lusso/`98/
GRIMECA Vespa PX/PE Ø 16mm
GRIMECA Vespa PX Lusso/T5/PK
Ø 20mm
Speedo Speedo Transmission
drive drivegear ration
Teeth t1 Art. No Teeth t2 I = t2/t1
13 94450000 11 0,85
12 94450000 10 0,83
12 9444000 9 0,75
10 15161400 8 0,80
15 61730000 12 0,80
16 94420000 12 0,75
16 94430000 12 0,75
16 94420000 12 0,75
16 94430000 12 0,75
