MOUNTING- AND SETTING INSTRUCTIONS SPEED SENSOR (PART NO. 50000250) MOUNTING INSTRUCTION SPEED SENSOR
2mm
9 mm 24 mm
22-23
12-13
5mm
Step 1 Step 1
Release the headlights safety clip. Remove the original speedometer cable,
Undo the speedometer bolt and
rubber and fixing plate from the suspension
the nut for the speedometer cable.
arm.
Remove speedo.
2.5 mm
Step 2 Step 2
Remove the original speedometer Place the included rubber gasket and speed
1 mm 35 mm
cable, rubber and fixing plate from
sensor into the suspension arm.
the suspension arm.
Step 3 Step 3
Place the included rubber Mount the speed sensor with the screw,
gasket and speed sensor
locking ring and washer that are included.
into the suspension arm.
CAUTION!
In the case of resistance,
CAUTION!
In the case of resistance,
carefully turn the wheel.
carefully turn the wheel.
3mm
24 mm
3 mm 1 mm
Step 4 Step 4
Mount the speed sensor and the bolt,
Attach the sensor to the old speedo cable
safety washer and washer that are
with sticky tape and pull it through the
included.
steering column.
2.5 mm
Step 5 Step 5
Attach the sensor to the old speedo Position the rubber gasket over the cable 35 mm
cable with sticky tape and pull it
connector followed by the cables.
through the steering column.
CAUTION!
Pay attention to wire colour
and order.
Cable colours:
1- black, 2 – red, 3 – white
1 2 3
Step 6 Step 6
Position the rubber gasket over the
Push the gasket completely into the
cable connector followed by the cables.
connection.
CAUTION!
Note the wire color and order.
Cable colours:
1- black, 2 – red, 3 – white
1 2 3
