WATERCONTROL-SYSTEM
The water-stop device protects against water damages caused by leaks on the fill
hose which could develop due to natural ageing of the hose.
In the water-stop system the leaking water fills the corrugated hose and activates a
stop valve which cuts off the water supply to the machine.
This fault is shown by a red sector on the window «A».
Would this occur, please refer to your Service Agent.
If the hose is not long enough for correct connection, it must be replaced with a longer
one. The hose can be obtained from your Service Agent.
Safety antitwist device
(press and twist to
remove the washer)
A
Red button blocked
valve indicator
8

WATER SOFTENER UNIT

Depending on the source of the supply,
water contains varying amounts of limestone
and minerals which are deposited on the
dishes leaving whitish stains and marks.
The higher the level of these minerals
present in the water, the harder the water is.
The dishwasher is fitted with a water
softener unit which, through the use of
special regenerating salt, supplies
softened water for washing the dishes.
The degree of hardness of your water can
be obtained from your water supply
company.
Regulating the water softener
The softener unit can treat water with a
hardness of up to 90°fH (French grading)
or 50°dH (German grading) through six
different settings.
The table below lists different degrees of
water hardness with the corresponding
setting for the softener unit.
Water
hardness
Indicator light
0 0-5 0-3 NO
1
Indicator light
6-15 4-9 YES
1
1
Indicator lights
16-30 10-16
2 YES
1,2
Indicator lights
17-25
*3 31-45 YES
1,2,3
Indicator lights
46-60 26-33
4 YES
1,2,3,4
Indicator lights
5 61-90 34-50
YES
1,2,3,4,5
"ON/OFF" button
* The water softener unit is set in the
factory at level 3, as this is suitable
for the majority of users.
According to the degree of hardness of
your water, regulate the softener unit in the
following way:
IMPORTANT
The dishwasher must be ALWAYS
off before start this procedure.
1. When the dishwasher is off, OPEN
the door.
2. Hold down the FIRST and the THIRD
"PROGRAMME" button (from the left)
while simultaneously pushing
"ON/OFF" button.
3. Release the buttons when some
"PROGRAMME SELECTION" indicator
lights up.
4. Press the "PROGRAMME" button for
the required water softener level (each
time the button is pressed a light will go
on). For level 5, press the "HALF
LOAD" option button.
5. Turn off the dishwasher pressing the
"ON/OFF" button to confirm the new
setting.
WARNING!
If any problem occurs, turn the
dishwasher off by pressing the
"ON/OFF" button and start the
procedure again from the beginning
(STEP 1).
Indicator lights 1 2 3 4
0
Levels 2
3
4
1
"HALF LOAD"
"PROGRAMME" buttons
option button
