Over several years' development of the Wingstabi Evolution, we have been able to create
an enormous database covering a vast range of model aircraft.
This has now made it possible for us to define an ideal basic set-up, with which you will
achieve outstanding results with virtually any model.
Which parameters have been changed for the Wingstabi-Evolution?
1.) Gyro gain offset values:
AIL -> easy Control = 0 / Classic = 30
ELE -> easy Control = 5 / Classic = 35
RUD -> easy Control = 25 / Classic = 55
The reason behind the different offset values for the Classic and Easy Control is the
variation in regulatory characteristics between the two versions.
2.) Differential gyro gain adjustment:
AIL = 18
ELE = 16
RUD = 14
3.) Adjusting the Direct values in the Classic system to 80
4.) Defining the Stop functions as:
AIL = 4
ELE = 2
RUD = 2
5.) The gyro sensor's low-pass filter has been reduced to 20Hz.
6.) The default for gyro suppression is set to 200 for the Easy Control and Classic.
