Focus DROPPER POST Informationsblatt Seite 6

INSTALL 6
REMOTE LEVER
7
1. Loosen the M4 screw on the remote lever
to three turns anticlockwise.
2. Move the lever to the desired position.
7
3. Tighten the M4 screw on the lever
REDUCE CABLE TENSION
If the lever is difficult to press, it may help to reduce the cable tension.
8
1. Turn the tension adjuster one to two turns anticlockwise to re-
duce tension.
INCREASE CABLE TENSION
If the lever moves too easily and the device is not working properly, it
may help to increase the tension:
8
2. Turn the tension adjuster clockwise to increase tension.
CLEANING
Never clean your bike with a pressure washer. Only use a soft cloth
slightly moistened with water to clean the seatpost. Do not use oily or
aggressive cleaning agents.
INFORMATION SHEET: DROPPER POST
6
by turning it two
6
to a maximum of 1.6 Nm.
10
1
Seat clamp
2
Upper seatpost
3 1
Lower seatpost
4 Release mechanism
5
Cable
6 Remote lever
2
7 M4 screw (1.2-1.6 Nm)
8 Tension adjuster
9
Set screw (3-4Nm)
M6 screw (8-10 Nm)
3
4
8
7
6
5
10
10
9
EN
