Loosen the self-locking nut(6)on one end of the
cylinder piston rod,and remove the installation
rod (3).After removing the parts,installthe
installation rod (3)into the engine installation
hole(as shown in the figure above);
Remove the bolt (7)from the middle hole of the
cylindrical triangle bracket bracket,adjust the
Angle of the engine,and fix the cylinder triangle
bracket to the engine with bolt(7)and nut(8)
corresponding to the
connection plate.Pay attention to the left and
right swing of the machine to ensure that the
cylinder will not interfere with the movement of
the engine after installation.
Adjust the engine Angle and cylinder piston rod
extension length.According to the gap between
the engine and cylindercorrectly
stainless steel C-clamp(5)into the appropriate
groove of the mounting
above)
After installation,the locking nut(4)should be
tightened to eliminate the operating clearance of
the cylinder.This willenhance your experience.
hole on the engine
install the
rod.(See figure
6
4
5
5
4
- 12 -
3
7
8
