FIG. 1
1. Bit protrusion
2. Trimmer base
3. Scale
4. Locking lever
5. Adjusting screw
6. Hex nut
FIG. 2
7. Switch ON/OFF
8. Speed adjusting dial
FIG. 3
9. Tighten
10. Loosen
11. Shaft
12. Collet nut
FIG. 4
13. Tighten
14. Loosen
15. Shaft lock
16. Collet nut
FIG. 5
17. Collet
18. Collet nut
FIG. 6
19. Dust nozzle
20. Screw
21. Trimmer base
FIG. 7
FIG. 8
22. Workpiece
23. Bit revolving direction
24. Feed direction
25. View from the top
FIG. 9
26. Feed direction
27. Bit revolving direction
28. Straight guide
FIG. 10
6
Explanation
FIG. 11
29. Bolt
30. Guide plate
31. Straight guide
32. Wing nut
FIG. 12
33. Clamping screw
34. Straight guide
35. Wing nut
36. Tool base
FIG. 13
37. Wing nut
38. Guide plate
39. Straight guide
40. Center hole A
41. Bolt
FIG. 14
42. Wing nut
43. Guide plate
44. Straight guide
45. Center hole B
46. Bolt
FIG. 15
47. Nail
48. Center hole
49. Straight guide
FIG. 16
FIG. 17
50. Clamping screw A
51. Adjusting screw
52. Clamping screw B
53. Guide holder
54. Trimmer guide
FIG. 18
55. Workpiece
56. Bit
57. Guide bushing
FIG. 19
FIG. 20
FIG. 21
58. Micro adjusting knob
59. Lock lever
60. Depth pointer & scale
61. Stopper bar knob
62. Fast-feed button
63. Stopper bar
64. Turret stops
FIG. 22
65. Bolt
66. Guide support
67. Wing nut 1
68. Wing bolts
69. Bolt
70. Wing nut 2
71. Guide plate
72. Straight guide
FIG. 23
FIG. 24
73. Screw
74. Plunge base
75. Template guide
FIG. 25
76. Bit
77. Base
78. Base protector
79. Template
80. Workpiece
81. Templet guide
FIG. 26
82. Limit mark
FIG. 27
83. Brush holder cap
